gb7jd.co.uk

ScottishBorders Amateur Radio

First dual mode digital repeater in Scotland

GB7JD transmit frequency 439.41250Mhz

GB7JD receive frequency 430.41250Mhz

TalkGroups and Use

It is advisable to check reflector connection before use !

Scotland NXDN reflector available on TG23551 RAN 1

Cross mode DMR/D-Star available slot 1 ( TG 6 ) for local users

Cross mode D-Star/Allstar on test slot 1 ( TG 6 ) for local users

DMR-default TG's-user activated for others

Brandmiester Network slot 2 ( TG2355 ) links to some Scottish Repeaters

Brandmiester Network slot 1 ( TG23551 ) Lothian and Borders DMR/NXDN link

DMR+ Network slot 1 ( TG8 ) links to some Scottish Repeaters

DMR+ Network slot 1 ( TG235 ) links to Phoenix UK TG 235

DMR+ Network slot 1 ( TG10 ) links to GB7EY - Selkirk -

D-Star-user activated for reflectors XLX602 and XLX604

Briefly press PTT & release to connect, then press PTT to begin QSO

Peanut connection via XLX602 [P]; D-Star/DMR via XLX604 [E]


mb6jd

Multi-Mode Simplex Gateway

MB6JD Equipment

GM340, transmit frequency 144.8250Mhz, receive frequency 144.8250Mhz

Rpi Model B Rev 2.0 (512MB)

YSF Gateway available

D-Star Gateway

user activated for all reflectors

DMR Gateway

Default Slot 2 ColorCode 5 TalkGroup 23550 Scotland Chat

All other TalkGroups are user activated, use 1 second PTT to activate

Slot 2 TalkGroup 7 ColorCode 5 ScottishBorders Only

Slot 2 TalkGroup 2355 ColorCode 5 BM Scotland Wide


mb7ijd

Internet linked FM simplex repeater

MB7IJD Equipment

Alinco DR06, transmit frequency 50.5200Mhz, receive frequency 50.5200Mhz

URI+

Raspberry PI3

default connection to Alaska Morning Net

GB3BT transmit frequency 145.700Mhz, receive frequency 145.100Mhz CTCSS [ J ]

URI+

Raspberry PI3



MB7AJD

Internet linked FM simplex repeater

MB7AJD operates on an attended basis

It is a low power experimental station

MB7AJD Equipment

Baofeng 888, transmit frequency 430.0750Mhz, receive frequency 430.0750Mhz

URI+

BeagleBoneBlack



MB7NJD

Internet linked AX25 URONode

MB7NJD Equipment

Motorola MC80, transmit frequency 433.6250Mhz, receive frequency 433.6250Mhz

PI-TNCx

RaspberryPi B+



GB7JED

Internet linked AX25 FBB Mailbox

GB7JED Equipment

Motorola MC80, transmit frequency 433.6250Mhz, receive frequency 433.6250Mhz

PI-TNCx

RaspberryPi 1



GB7BDX

Internet linked DXSpider Cluster

GB7BDX Equipment

Tait 192, transmit frequency 70.4875Mhz, receive frequency 70.4875Mhz

PI-TNCx

RaspberryPi B+
